Panelboard – UL67, also known as a Low Voltage Distribution Panelboard, is an important low-voltage electrical distribution product used to distribute power from an upstream switchboard, switchgear, transformer, or main distribution panel to multiple branch circuits. It is commonly used in commercial buildings, residential buildings, industrial facilities, schools, hospitals, office buildings, public infrastructure, and other low-voltage power distribution systems.
| Standard Reference | UL67-oriented design |
|---|---|
| Breaker Mounting | Bolt-on, rail-type bolt-on, plug-on, or plug-in options |
| Rated Voltage | Low-voltage system, project-based configuration |
| Rated Current | Customized according to project requirements |
| Protection Design | Branch circuit protection, overload protection, short-circuit protection |
| Enclosure Type | Wall-mounted or floor-mounted enclosure according to size and installation condition |
Solo configuración típica. Las potencias nominales definitivas se confirman en función de los requisitos del proyecto.
Panelboard – UL67 is widely used in low-voltage electrical distribution systems where multiple branch circuits need to be protected, organized, and distributed. It is commonly installed downstream of transformers, LV switchgear, LV switchboards, or main distribution boards.
